TPEE Membrane
TPEE is a type of PET. As a type of PET material, The elasticity of rubber material & strength of engineering plastic material, waterproof, high moisture permeability, high-temperature resistance, yellowing resistance and recyclability, TPEE features in high mechanical strength, good elasticity, strong impact resistance, creep resistance, cold resistance, bending fatigue resistance, oil resistance, chemical resistance and solvent erosion. With excellent melting stability and sufficient thermoplasticity, TPEE can be processed by various thermoplastic processing techniques, such as extrusion, injection, blow molding, rotational molding, and melt casting etc.
Physical Properties Report
| UREAMAX® |
|
Physical Properties/Test Method |
| TPU film |
Specification |
Thickness
（mm） |
M.P.R（mmH2O） |
M.V.P
（g/㎡/day) |
M.V.P
（g/㎡/day) |
M.V.P
（g/㎡/day) |
Hardness
(shore A) |
Tensile Strength
(kg/c㎡） |
Tear Strength
(kg/c㎡） |
Elongation（%） |
Characteristics and Applications |
|
Style NO |
Type |
Color |
ASTM D1777 |
JIS L 1092 B |
ASTM E96 BW 1995 |
JIS L 1099 B-1 |
JIS L 1099 A-1 |
ASTM D2240 |
ASTM D412 |
ASTM D624 |
ASTM D412 |
| TPEE Transparent film |
TPEE-4001S |
60" |
Transparent |
0.012~0.02 |
10000 |
>8000 |
>130000 |
>3500 |
88±3 |
>120 |
|
>50 |
Waterproof, moisture permeable, outdoor, jacket, storm suit, ski suit, etc |
| TPEE-4001S |
60" |
Transparent |
0.03 |
10000 |
>5000 |
>30000 |
>3000 |
88±3 |
>120 |
|
>50 |
Waterproof, moisture permeable, outdoor, jacket, storm suit, ski suit, etc |
| TPEE White film |
TPEE-4001WS |
60" |
White |
0.012~0.02 |
10000 |
>7000 |
>100000 |
>3000 |
88±3 |
>100 |
|
>50 |
Waterproof, moisture permeable, outdoor, jacket, storm suit, ski suit, etc |
| TPEE-4001WS |
60" |
White |
0.03 |
10000 |
>4000 |
>20000 |
>2500 |
88±3 |
>100 |
|
>50 |
Waterproof, moisture permeable, outdoor, jacket, storm suit, ski suit, etc |
| TPEE Black film |
TPEE-4001BS |
60" |
Black |
0.012~0.02 |
10000 |
>7000 |
>100000 |
>3000 |
88±3 |
>100 |
|
>50 |
Waterproof, moisture permeable, outdoor, jacket, storm suit, ski suit, etc |
| TPEE-4001BS |
60" |
Black |
0.02 |
10000 |
>4000 |
>20000 |
>2500 |
88±3 |
>100 |
|
>50 |
Waterproof, moisture permeable, outdoor, jacket, storm suit, ski suit, etc |
| *The data and information provided are for reference only and are not guaranteed, please test the TPU film before the final application |
Nanxiong TPEE film has the characteristics of waterproof and moisture permeability, windproof and keeping warm, green and environmental protection, high and low temperature resistance, wear resistance and aging resistance. It is widely used in casual clothing, cold-proof clothing, protective clothing, outdoor sports clothing, bags, life-saving products, aquatic products, outdoor products, sports products and other industries.
Application
NAM LIONG has become a large international conglomerate with bases all over the world. The basis of NAM LIONG is composed of businesses in three major industries – Sport and recreation manufacturing, outdoor activities equipment manufacturing and safety protection equipment manufacturing. Functional Material Dept - One important marketing department with more than 60 staff, professional TPEE Membrane supplier, manufacturer & factory in China. Professional and independent production of various high polymer functional membranes. With advanced equipment, professional production technology, mature R & D team, and excellentservice and quality, our products are sold in Chinese mainland, Japan, Korea, Russia, Southeast Asia, Europe and America. Welcome to visit our company and factory. Custom TPEE Membrane direct from us, we also wholesale in bulk. Low MOQ. OEM/ODM TPEE Membrane is welcomed.
Recommended Products
-
GRS & Bluesign TPU Membrane
We passed GRS global certification recyclable standard in 2019. We can offer TPU membrane and TPEE membrane with 50%,75% and 100% recycled materials, and maintain excellent physical properties which c...
-
Bio-based TPU Membrane
Bio-based TPU film is widely used in garments, home textiles and other fabrics lamination. It is not only waterproof and moisture-permeable, windproof and warm, but also greener and healthier, energy-...
-
PU Photoluminescence Membrane
Physical Properties Report
UREAMAX®
Physical Properties/Test Method
TPU film
Specification
Thickness（mm）
M.P.R（mmH2O）
M.V.P（g/㎡/day)
M.V.P（g/㎡/day)
M.V.P（g/㎡/day)
Hardness(shore A)
Tensile S...
-
Rejuvenate Energy Membrane
Functions of rejuvenating membrane:
1.Functions of far-infrared Ray,increase our body temperature
2.Increase blood oxygen concentration during physical exercise
3.Promote lactic acid metabolism and r...
-
Laminate Material
Product characteristics： High waterproof resistance（TPU film Thickness＞0.050MM）Good airtightness
Processing methods： High-frequency hot pressing / ultrasonic welding
Outdoor sports accessories: dry b...
-
PES / POLYESTER MEMBRANE
Physical Properties Report
UREAMAX®
Physical Properties/Test Method
PES /TPEE film
Specification
Thickness（mm）
M.P.R（mmH2O）
M.V.P（g/㎡/day)
M.V.P（g/㎡/day)
M.V.P（g/㎡/day)
Hardness(shore A)
Ten...
NANXIONG NEWS
-
2024-01-08 15:48:33
TPEE (Thermoplastic Polyester Elastomer) Membrane is a new high-performance material that is rapidly gaining popularity across various industries. TPEE is known for its excellent properties, including...
-
2024-01-08 15:48:33
TPU material is strongly welcomed by the market because of its performance and environmental protection, and there are almost all the places where PVC can be used are replaced by TPU, because the perf...
-
2024-01-08 15:48:33
TPU,the abbreviation of "Thermoplastic Polyurethane", it has excellent high tension, high tensile strength, toughness and aging resistance. It is a mature environmentally friendly material, one of the...
-
2024-01-08 15:48:33
TPU, short of thermoplastic polyurethane, is a versatile material with a wide range of applications due to its unique combination of properties, including flexibility, durability, and chemical resista...
-
2024-01-08 15:48:33
Nanliang International Co., Ltd. - Tainan Branch will participate in the A+A exhibition in Dusseldorf, Germany from November 5th to November 8th, 2019. This industrial safety exhibition has now develo...
-
2024-01-08 15:48:33
Xiao Dengbo, president of Nanliang Group, known as the king of Taiwan's shoe materials, was awarded an honorary doctorate in management from Chaoyang University of Science and Technology on the 20th, ...
Industry Knowledge
What is TPEE film ?
TPEE film is a non-porous hydrophilic film, which has excellent moisture permeability and high waterproof strength, and will not be clogged due to pollution. In addition, after laminating polyester fabric, a single material can be fully recycled and reused.
What is the features of TPEE film ?
TPEE film is a film processed from thermoplastic polyester elastomer. It has the advantages of both the elasticity of rubber material and the strength of engineering plastic material. It has high waterproof and moisture permeability, and it also has low temperature and high temperature resistance. , good recyclability and other physical properties, are widely used in the lamination processing of outdoor clothing fabrics, and the composite processing of bedding fabrics.
What is relationship between polyester film / PET film /PBT film and TPEE film ?
PET ，Polyethylene terephthalate, Polyester film, PET film, PBT film and TPEE film are different names for the same film.
PET, Polyethylene terephthalate, namely polyethylene terephthalate, commonly known as polyester resin, is the most important variety of thermoplastic polyester, mainly used in fibers, films and engineering plastics, and blow molding products, etc. PET fibers are mainly used In the textile industry, TPEE is a kind of PET.
How is TPEE film recycled ? TPEE?
As a kind of polyester film, when the polyester fabric is laminated, a single material can be completely recycled and recycled directly, that is, the damaged polyester clothes or bedding can be recycled directly without separating the film from the fabric, free of classification, easy Recycle.
