PU Biomass Membrane
Bio-based PU film produced by coating process of PU biomass, is a green and environmentally friendly polymer material with good elasticity, soft hand feel, good temperature resistance, high waterproof and great moisture permeability .
Introduction to PU biomass technology
In January 2012, Taiwan Nanliang Group officially obtained DuPont Tate & Lyle bio products from the United States ™ The company developed susterra, which is renewable from glucose in plants ® Biomass technology, Add the biomass 1.3PDO extracted from corn to PU with excellent waterproof and moisture permeability.
Biomass feedstock sources and energy saving
With continuous trial and research, DuPont has developed corn variety that can grow under various severe environments, solving the hidden worries of general biomass materials - the contradiction between the development of biomass materials and the human food .
Making local planting and local production in real, from cradle to gate and cradle to grave, are committed to reducing the carbon footprint and reducing the burden on the earth, Compared with petroleum based 1,3 propylene glycol and propylene glycol products, the energy consumption is reduced by 40%, and the carbon dioxide (CO2) emission is also significantly reduced by 40%.
PU biofilm physical properties
| ECOMATE® |
|
Physical Properties/Test Method |
|
| PU Membrane |
Specification |
Thickness（mm） |
Waterproofness（mmH2O） |
Humidity permeability（g/㎡/day) |
Humidity permeability（g/㎡/day) |
Hardness(shore A) |
Tensile Strength(kg/c㎡） |
Elongation（%） |
Brief description of properties and applications |
bio-based content |
|
Model |
Category |
Colour |
ASTM D1777 |
JIS L
1092 B |
JIS L
1099 B-1 |
JIS L
1099 A-1 |
ASTM D2240 |
ASTM D412 |
ASTM D412 |
| PU bioplasmic film |
Medium transparent 0.015~0.025 |
60" |
Transparent haze |
0.015~0.025 |
10000 |
＞25000 |
＞4000 |
80±3 |
＞100 |
＞150 |
Waterproof, cold-proof, jackets, coats, rashers, etc. |
5%-30% |
| Medium Transparent 0.015~0.025 |
60" |
White |
0.015~0.025 |
10000 |
＞20000 |
＞4000 |
80±3 |
＞100 |
＞150 |
Waterproof, cold-proof, jackets, coats, rashers, etc. |
5%-30% |
| High transparent 0.015~0.025 |
60" |
Transparent haze |
0.015~0.025 |
10000 |
＞55000 |
＞4000 |
80±3 |
＞100 |
＞150 |
Waterproof, cold-proof, jackets, coats, rashers, etc. |
5%-30% |
| High translucent white 0.015~0.025 |
60" |
White |
0.015~0.025 |
10000 |
＞50000 |
＞4000 |
80±3 |
＞100 |
＞150 |
Waterproof, cold-proof, jackets, coats, rashers, etc. |
5%-30% |
The higher the *biomass content, the lower the moisture permeability. The above data and usage are for reference only and are not guaranteed, please test the suitability beforehand.
NAM LIONG has become a large international conglomerate with bases all over the world. The basis of NAM LIONG is composed of businesses in three major industries – Sport and recreation manufacturing, outdoor activities equipment manufacturing and safety protection equipment manufacturing. Functional Material Dept - One important marketing department with more than 60 staff, professional PU Biomass Membrane supplier, manufacturer & factory in China. Professional and independent production of various high polymer functional membranes. With advanced equipment, professional production technology, mature R & D team, and excellentservice and quality, our products are sold in Chinese mainland, Japan, Korea, Russia, Southeast Asia, Europe and America. Welcome to visit our company and factory. Custom PU Biomass Membrane direct from us, we also wholesale in bulk. Low MOQ. OEM/ODM PU Biomass Membrane is welcomed.
