Hot Product
Home Textiles
Home Textiles

TPU film has become an important material in the home textile industry due to its excellent elasticity, abrasion resistance, waterproof and breathable performance, and eco-friendly properties.

Waterproof Mattress Protector

TPU has become the preferred material for mattress protectors due to its excellent waterproof performance, breathability, and eco-friendly properties.

  • ✰ The TPU film physically blocks liquid penetration while allowing water vapor to pass through, helping keep the mattress dry and comfortable.
  • ✰ TPU is gradually replacing PVC films and PU coatings because it is non-toxic, plasticizer-free, recyclable, and meets safety standards for infant products.
  • ✰ It offers excellent resistance to washing, abrasion, and aging, and can withstand high-temperature cleaning, such as machine washing at 90°C.
  • ✰ Compared with traditional PVC or plastic materials, TPU film is softer and helps minimize rustling noise, improving overall sleep comfort.
  • ✰ Customization services are available, with optional functions such as antibacterial and anti-dust mite treatments to meet the needs of hospitality, healthcare, and medical applications.
Waterproof Mattress Protector
Blackout Curtains / Roller Blinds

TPU is plasticizer-free and compliant with environmental standards. It can be bonded to fabrics through hot-melt adhesive lamination processes, such as PUR or PU adhesive lamination, helping avoid adhesive contamination issues commonly associated with traditional coating methods.

With its excellent light-blocking performance, eco-friendly properties, and processing versatility, TPU has become an important material choice for home textiles, automotive interiors, and outdoor applications. It is gradually replacing PVC coatings and conventional woven blackout fabrics.

TPU blackout films can be laminated with various fabrics to produce full blackout curtains and tent materials that combine waterproof performance and wash resistance. These materials are widely used in residential curtains, healthcare curtains, public spaces, and other light-blocking applications.

In automotive applications, TPU films are used for sunroof shades, offering high flexibility, ultra-thin profiles, and flame-retardant performance. Their rollable structure enables compact storage and provides a lightweight alternative to traditional rigid sunshades.

Blackout Curtains / Roller Blinds
Physical Property

Membranes for Home Textiles

TPU film has become an important material in the home textile industry due to its excellent elasticity, abrasion resistance, waterproof and breathable performance, and eco-friendly properties.

Category Color Stycle Thickness
 (MM)
Width
(M)
W.V.P
g//day)
JIS L 1099 B-1
W.V.P
g//day)
ASTM E 96 BW 2000
W.P.R
mmH2O
JIS L 1092 B
Features
Membranes for waterpoof mattress protector  TPU
membrane
white low breathable 0.012~0.05mm 1.5~ 2.6 / / > 10000 1. washable resistance;
2. excellent waterpoofness
transparent 0.012~0.05mm 1.5~ 2.6 / / > 10000
white medium breathable 0.012~0.03mm 1.5~ 2.4 > 30000 > 4000 > 10000 1. washable;
2. waterpoofness and moisture permeabilty
3.with PE carrier
transparent 0.012~0.03mm 1.5~ 2.4 > 35000 > 4500 > 10000
white high breathable 0.012~0.025mm 1.5~ 2.4 > 50000 > 5500 > 10000
transparent 0.012~0.025mm 1.5~ 2.4 > 60000 > 6500 > 10000
 TPEE
membrane
white low breathable 0.015~0.04mm 1.55~ 2.4 / / > 10000 1. bonded with polyester fabric to recycle directly
2. excellent waterproofness
transparent 0.015~0.04mm 1.55~ 2.4 / / > 10000
white medium breathable 0.015~0.025mm 1.55~ 2.4 > 60000 > 4000 > 10000 1. bonded with polyester fabric to recycle directly
2. excellent waterproofness and good vapor permeability
3.with PE carrier
transparent 0.015~0.025mm 1.55~ 2.4 > 70000 > 5000 > 10000
white high breathable 0.015~0.025mm 1.55~ 2.4 > 90000 > 6000 > 10000
transparent 0.015~0.025mm 1.55~ 2.4 > 100000 > 7000 > 10000
Membranes for Blackout Curtains / Roller Blinds Blackout TPU membrane  Black single layer 0.015~0.05mm 1~ 3 / / > 10000 1.light-blocking performance and waterproof
2.suitable for one layer or two layers lamination
Black/White two layers 0.03~0.06mm 1~ 3 / / > 10000 1.Excellet light-blocking performance and waterproof
2.Colors can be customized
Black/Gray two layers 0.03~0.06mm
White/black/
white
three layers 0.06~0.1mm 1~ 3 / / > 10000 1.Ordinary white/black/white film or high/low temperature film
2.Suitable for one layer /two layer lamination
Blackout and FR TPU membrane  Black single layer 0.02~0.03mm 1~ 3 / / > 10000 1.light-blocking performanceand flame retardant
2.Color  can be customized
3.Suitable for one layer /two layer lamination
Black/White two layers 0.03~0.06mm 1~ 3 / / > 10000
Black/Silver two layers 0.03~0.06mm 1~ 3 / / > 10000
Blackout TPEE membrane black single layer 0.018~0.04mm 1~ 3 / / > 10000 1.light-blocking performance
2.Bonded with polyester fabric to recycle directly

Remarks:
1. Film specifications can be customized to meet customer requirements, including color, thickness, and width.
2. GRS-certified film is available upon request.
3. The data above is provided for reference only. Please refer to the final test results based on the actual samples received.
